API

Import scirpy together with scanpy as

import scanpy as sc
import scirpy as ir

For consistency, the scirpy API tries to follow the scanpy API as closely as possible.

Input/Output: io

Note

In scirpy v0.7.0 the way VDJ data is stored in adata.obs has changed to be fully compliant with the AIRR Rearrangement schema. Please use upgrade_schema() to make AnnData objects from previous scirpy versions compatible with the most recent scirpy workflow.

upgrade_schema(adata)

Update older versions of a scirpy anndata object to the latest schema.

The following functions allow to import V(D)J information from various formats.

read_h5ad(filename[, backed, as_sparse, …])	Read .h5ad-formatted hdf5 file.
read_10x_vdj(path[, filtered])	Read IR data from 10x Genomics cell-ranger output.
read_tracer(path)	Read data from TraCeR ([SLonnbergP+16]).
read_bracer(path)	Read data from BraCeR ([LEM+18]).
read_airr(path[, use_umi_count_col, …])	Read data from AIRR rearrangement format.
from_dandelion(dandelion[, transfer])	Import data from Dandelion ([SRB+21]).

Scirpy can export data to the following formats:

write_airr(adata, filename)	Export IR data to AIRR Rearrangement tsv format.
to_dandelion(adata)	Export data to Dandelion ([SRB+21]).

To convert own formats into the scirpy Data structure, we recommend building a list of AirrCell objects first, and then converting them into an AnnData object using from_airr_cells(). For more details, check the Data loading tutorial.

AirrCell(cell_id[, cell_attribute_fields, …])	Data structure for a Cell with immune receptors.
from_airr_cells(airr_cells[, include_fields])	Convert a collection of AirrCell objects to AnnData.
to_airr_cells(adata)	Convert an adata object with IR information back to a list of AirrCell objects.

Preprocessing: pp

merge_with_ir(adata, adata_ir[, on])	Merge adaptive immune receptor (IR) data with transcriptomics data into a single AnnData object.
merge_airr_chains(adata, adata2)	Merge two AnnData objects with IR information (e.g.
ir_dist(adata, *[, metric, cutoff, …])	Computes a sequence-distance metric between all unique VJ CDR3 sequences and between all unique VDJ CDR3 sequences.

Tools: tl

Tools add an interpretable annotation to the AnnData object which usually can be visualized by a corresponding plotting function.

Generic

group_abundance(adata, groupby[, …])

Summarizes the number/fraction of cells of a certain category by a certain group.

Quality control

chain_qc(adata, *[, inplace, key_added])

Perform quality control based on the receptor-chain pairing configuration.

Define and visualize clonotypes

define_clonotypes(adata, *[, key_added, …])	Define clonotypes based on CDR3 nucleic acid sequence identity.
define_clonotype_clusters(adata, *[, …])	Define clonotype clusters.
clonotype_convergence(adata, *, key_coarse, …)	Finds evidence for Convergent evolution of clonotypes.
clonotype_network(adata, *[, sequence, …])	Computes the layout of the clonotype network.
clonotype_network_igraph(adata[, basis])	Get an igraph object representing the clonotype network.

Analyse clonal diversity

clonal_expansion(adata, *[, target_col, …])	Adds a column to obs recording which clonotypes are expanded.
summarize_clonal_expansion(adata, groupby, *)	Summarizes clonal expansion by a grouping variable.
alpha_diversity(adata, groupby, *[, …])	Computes the alpha diversity of clonotypes within a group.
repertoire_overlap(adata, groupby, *[, …])	Compute distance between cell groups based on clonotype overlap.
clonotype_imbalance(adata, replicate_col, …)	Aims to find clonotypes that are the most enriched or depleted in a category.

V(D)J gene usage

spectratype(adata[, groupby, combine_fun, …])

Summarizes the distribution of CDR3 region lengths.

Plotting: pl

Generic

embedding(adata, basis, *[, color, …])

A customized wrapper to the scanpy.pl.embedding() function.

Tools

Every of these plotting functions has a corresponding tool in the scirpy.tl section. Depending on the computational load, tools are either invoked on-the-fly when calling the plotting function or need to be precomputed and stored in AnnData previously.

alpha_diversity(adata, groupby, *[, …])	Plot the alpha diversity per group. `
clonal_expansion(adata, groupby, *[, …])	Visualize clonal expansion. `
group_abundance(adata, groupby[, …])	Plots the number of cells per group, split up by a categorical variable. `
spectratype(adata[, cdr3_col, combine_fun, …])	Show the distribution of CDR3 region lengths. `
vdj_usage(adata, *[, vdj_cols, …])	Creates a ribbon plot of the most abundant VDJ combinations. `
repertoire_overlap(adata, groupby, *[, …])	Visualizes overlap betwen a pair of samples on a scatter plot or `
clonotype_imbalance(adata, replicate_col, …)	Aims to find clonotypes that are the most enriched or depleted in a category.
clonotype_network(adata, *[, color, basis, …])	Plot the Clonotype network. `

Base plotting functions: pl.base

bar(data, *[, ax, stacked, style, …])	Basic plotting function built on top of bar plot in Pandas.
line(data, *[, ax, style, style_kws, fig_kws])	Basic plotting function built on top of line plot in Pandas.
barh(data, *[, ax, style, style_kws, fig_kws])	Basic plotting function built on top of bar plot in Pandas.
curve(data, *[, ax, curve_layout, shade, …])	Basic plotting function for drawing KDE-smoothed curves.

Plot styling: pl.styling

apply_style_to_axes(ax, style, style_kws)	Apply a predefined style to an axis object.
style_axes(ax[, title, legend_title, xlab, …])	Style an axes object.

Datasets: datasets

wu2020()	Return the dataset from [WMdA+20] as AnnData object.
wu2020_3k()	Return the dataset from [WMdA+20] as AnnData object, downsampled to 3000 TCR-containing cells.
maynard2020()	Return the dataset from [MMR+20] as AnnData object.

Utility functions: util

graph.layout_components(graph[, …])	Compute a graph layout by layouting all connected components individually.
graph.layout_fr_size_aware(graph, *[, k, …])	Compute the Fruchterman-Reingold layout respecting node sizes.
graph.igraph_from_sparse_matrix(matrix, *[, …])	Get an igraph object from an adjacency or distance matrix.

IR distance utilities: ir_dist

sequence_dist(seqs[, seqs2, metric, cutoff, …])

Calculate a sequence x sequence distance matrix.

distance metrics

DistanceCalculator(cutoff)	Abstract base class for a CDR3-sequence distance calculator.
ParallelDistanceCalculator(cutoff, *[, …])	Abstract base class for a DistanceCalculator that computes distances in parallel.
IdentityDistanceCalculator([cutoff])	Calculates the Identity-distance between CDR3 sequences.
LevenshteinDistanceCalculator([cutoff])	Calculates the Levenshtein edit-distance between sequences.
HammingDistanceCalculator([cutoff])	Calculates the Hamming distance between sequences of identical length.
AlignmentDistanceCalculator([cutoff, …])	Calculates distance between sequences based on pairwise sequence alignment.
